3M Scotch® Vinyl Electrical Tape Super 88, 3/4 in x 66 ft – Black

Legacy 3M Model: 80610833867

Scotch® Vinyl Electrical Tape Super 88 is an 8.5 mil thick, premium grade, all weather tape that is designed to provide a protective jacket and primary electrical insulation for splices up to 600V. The flame retardant tape withstands a temperature range of 0 to 221 °F ( 18 to 105 °C).

The combination of the pressure-sensitive, rubber-resin adhesive and the PVC backing offers excellent electrical and mechanical protection

Provides high resistance to UV rays, abrasion, moisture, alkalis, acids, corrosion and varying weather conditions

Provides a protective jacket and electrical insulation for splices and cables

Made of durable PVC

Withstands a temperature range of 0 to 221 °F (-18 to 105 °C)

UL Listed, CSA Certified and RoHS 2011/65/EU Compliant

SKU: 260041,3M,88 Category:
Buy Online

Scotch Vinyl Electrical Tape Super 88 is an 8.5 mil thick, premium grade, all weather tape that is designed to provide a protective jacket and primary electrical insulation for splices up to 600V. The flame-retardant tape withstands a temperature range of 0 to 221F (-18 to 105C).

Scotch Vinyl Electrical Tape Super 88 is thicker for heavy-duty use yet highly conformable for a smooth wrap for every application. The pressure-sensitive rubber-based adhesive is compatible with solid dielectric cable insulations, rubber and synthetic splicing compounds as well as epoxy and polyurethane resins.

Designed to perform continuously, it can be used for indoor or outdoor applications to inhibit the corrosion of electrical conductors and provide UV protection.

It has excellent resistance to abrasion, moisture, alkalis, acids and corrosion.

Elastic backing and aggressive adhesive provide moisture-tight electrical and mechanical protection with minimum bulk. Use for permanent low voltage primary and secondary insulation, cable jacketing, mechanical protection and padding.

Additional information

Max Operating Temp (°C)

105

Overall Length (cm)

20.11581835

Overall Width (cm)

1.9

Product Color

Black

Tape Thick w/o Liner (mm)

0.216

Adhesive Type

Rubber

Application

Electrical Maintenance

Backing (Carrier) Material

PVC

Elongation At Break

250

Elongation At Break UOM

%

Inner Billing Unit

RLS

Inner Height

3.7 INCH

Inner Length

8.94 INCH

Inner Weight

2.85 LBS

Inner Width

3.7 INCH

Max Operating Temp (°C) UOM

Degree

Max Operating Temp (°F)

220

Max Operating Temp (°F) UOM

Degree

Min Operating Temp (°C)

-18

Min Operating Temp (°C) UOM

Degree

Shelf Life - Years

5

Tape Grade

Premium

Tensile Strength (Metric)

35

Tens. Str. (Metric) UOM

N/10mm

Tape Thick W/O Liner (Imp)

8.5

Tape Thick W/O Liner(Imp)UOM

mil

Voltage Rating

600 V
