LM-550A2/PC Printer
MAX LETATWIN LM-550A2BH Printer is a portable, high-speed thermal transfer printer designed for control panel marking, wire numbering, and device labelling. It excels in printing directly onto heat-shrink and PVC tubing, and printing on MAX polyester tapes for marker strip labelling. The printer’s unique features include the capability to make both half-cut and full-cut parts, a warming element and optional battery power capability. Users can simply connect a computer and print directly to the machine or save marker data to the machine’s large internal memory and take it with you on-site though the LETATWIN PC Editor and driver software.
Enquire Now
MAX LETATWIN LM-550A2 Printers
- Half Cut Function
- High speed printing, 40mm/sec (without half cut), 52pcs/min (29mm-long half cut)
- PC connect with USB, Auto cad data easy transfer
- Large internal memory, large ram 250,000 characters
- Review Function
- Integrated Keyboard
- Longer Roll Length of the consumables- Black ink ribbon is 110m/roll, while ink ribbon is 70m/roll.- White Tape Cassette is 16 meters
- Compact and Handy
Download Brochure
Specifications
| Items | Contents |
| Name | ELECTRONIC LETTERING MACHINE LM-550A2BH PC |
| Dimensions | 295(W) x 293(D) x 94(H)mm |
| Weight | 2.4kg |
| Printing Method | Thermal transfer method (300dpi) |
| Display | LCD dot matrix:64 x 160 Pixel(Backlit) |
| Printing Speed | 40mm/s(Standard) 20mm/s(Low temperature mode) |
| Maximum Printing Length | Tube : 100m，Tape :5m By multiple copy printing,maximum 30copies, upto Tube ;100m, Tape ;7m |
| Maximum number of characters to input | 5,000 characters per file |
| Character size | 1.3 , 2 , 3 , 4 , 6mm height |
| Usable Tube | Ø1.5mm ~ 8.0mm(VinylTubing) [For GRIP TUBE,Ø1.5 ~ 2.0mm tubes, the dedicated attachment(standard accessory)is required.] Ø2.0mm ~6.5mm(Heat Shrink Tubing) |
| Usable Tape | Width 5,9,12mm(Max genuine tape) |
| Usable ID Plate | 2.5/4.1/4.6/6.3/9.0mm wide. *ID Plate Attachment Only compatible with MAX brand 4.1mm wide. |
| Tube Cutting Method | Auto half cut, manual full cut |
| Internal Memory | 250,000 characters (Maximum 50 files) |
| External Memory | USB memory |
| Interface | USB 2.0 full speed |
| Power Supply | DC12V, 4.2A *Use only specified AC Adapter (100V~240V) included in the package |
| Power Consumption | Max 40W |
| Operating Environment | 10°C to 35°C |
